金运cad视觉扫描系统在于实现数码印刷工艺流程的无缝对接和高度自动化，讲设计放码、排版等工艺以.省成本的方式集成到一个系统中处理，并直接输出eps、pdf文件格式给打印机，.终通过高效率的自动化视觉扫描系统完成印刷材料的囧准裁切

this technology aims to the highly automatically process, seamless in-line integration for the whole progress this digital printing solution is based on a proprietary technology capable to import, scale, imposition and print high-quality printable files such as eps or pdf, this will be a breakthrough to simplify the whole process for digital printing. we are not only providing the cutting system, but also providing the whole process include software package golden pattern designer golden cad nesting, golden laser cad scanning vision cut.

1设计 design

设计师可以在金运cad制图设计软件中对设计图行进行放码，修改

with the golden pattern designer software, designers can merge the graphical content with the shapes designed and graded in cad application

2. 加工前准备pre-production

讲设计好的图形在auto marker排版软件里排版，生成pdf格式同于打印

auto marker nesting pdf to nest, nests the designed shapes and sends the result directly to a wide format printer

3. 打印printing

将排版好生成的pdf文件传送到打印机进行打印并进行热转印

nesting direct to printing ,and then dye sublimation to textile

4切割 cutting

激光视觉切割系统对成卷热转印布料进行扫描，相机提出印刷轮廓并将信息传送到电脑和切切割机，激光切割机自动连续切割

vision laser machine scans the sublimation printed rolls fabric, detect the contour and information has been sent to the pc and laser cutter, and the laser will cut automatically

金运cad视觉扫描系统流程优势

what are the benefits of golden cad vision scanning system?

? 简化流程 simplify the process

节省60%人工 save 60% labor cost

节省35%的损耗-转印纸/打印时间/布料 save consumable up to 35%-transfer paper/print time/materials

节省10%的油墨 save ink consumption up to 10%

节省空间，节省库存损耗/save space, save storage cost

减少废品率保证产品质量/decrease defect products and ensure high quality
